Litime 12V 230Ah Plus Lithium LiFePO4 Battery Deep Cycle W/ Low-Temp Protection
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Energy Density | 65.1Wh/lb |
| Size | 19*6.7*9.5 inch |
| Wattage | 2560W |
| MPN | L12V230-200-LTCP-4-A150 |
| Low-Temperature Charging Protection Auto Recovery | Yes (41℉/5℃) |
| Max. Continuous Charge Current | 200A |
| Energy | 2944Wh |
| Voltage | 12.8V |
| Recommend Charge Current | 46A (0.2C) |
| Max. Expansion (Parallel & Series) | 4P4S |
| Terminals | M8 bolts |
| Warranty | 5 Years |
| Charge Temperature | 0℃ to 50℃ / 32℉ to 122℉ |
| Weight | 45.22 lbs |
| Max. Continuous Discharge Current | 200A |
| Brand | LiTime |
| Cycle Life | up to 15,000 cycles |
| Protection Class | IP65 |
| Type | Grade A LiFePO4 Battery |
| BMS Board | 200A |
| Max. Discharge Current 5 Seconds | 600A |
| Resistance Properties | Waterproof |
| Country/Region Of Manufacture | China |
| Application | Agriculture/Farming |
| Low-Temperature Protection | Yes (32℉/0℃) |
Tips of Using Litime Batteries• Can not be used as a starter battery.• Can not be used to power golf carts.Battery AccessoriesBolts and caps are under the orange stickers.Premise of Battery Connections• The same model (capacity & voltage & BMS).• The same brand.• Recent purchases (within 3 months).Delivery Range and TimelinesThe battery will be shipped from our warehouses in CA, TX, PA and GA. ETA: 1-3 working days; the actual time may vary for the inventory situation. 【Low-Temp Protection】 The new upgraded 12V 230Ah LTCP LiFePO4 battery has built-in low-temperature charging protection that will auto-cut the battery off from charging when the cell temperature is lower than 32℉, preventing the battery cells from being damaged from charging under the freezing point. 【High Safety and Reliability】 Experience peace of mind with A-level LiFePO4 battery cells, which are free from mercury, lead, and other toxic substances. ABS flame-retardant plastic and IP65 waterproof level provide protection against fire and water. The intelligent 200A BMS board prevents over-charging, over-discharging, and short-circuiting, ensuring a safer and more reliable battery. 【6X Cost-effectiveness】 Enjoy superior cost savings with the LiTime 12V 230Ah Plus LiFePO4 battery, which offers a price-to-lifetime ratio of $0.21 per deep cycle and lasts up to 10 years with 4000 full discharge-charge cycles. Save $1.21 per cycle compared to lead-acid batteries, which only last 200 to 500 cycles. Plus, no regular maintenance is required, saving you time and effort. 【Ultra-long Continuity】 Power your devices with the built-in 200A BMS board, supporting a maximum load of 2560W. A fully charged 12.8V 230Ah Plus LiFePO4 battery provides 2944Wh of usable energy, enough to power 1kWH of housing demand for nearly three days. This LiTime battery is 50% more powerful than similar-sized lead-acid batteries, offering a low self-discharge rate and minimal capacity loss. 【3X Energy Density】 At 5.07Ah per pound, the LiTime 12V 230Ah Plus LiFePO4 battery boasts 3 times the energy density and a lighter weight compared to lead-acid batteries. Benefit from longer-lasting power and increased portability, thanks to Tier-1 A-level prismatic LiFePO4 battery cells in a 4-cell series configuration. Spec.Model12V 230 Plus LTCPBATTERYCell TypeLiFePO4 PrismaticWarranty5 YearsCycle Life4000 cycles at 100% DOD, 6000 cycles at 80% DOD, 15,000 cycles at 60% DODNominal Voltage12.8VRated Capacity230AhEnergy2944WhMax. Expansion (Parallel & Series)4P4SInternal Resistance≤40mΩCertificationsUL, FCC, CE, RoHS, UN38.3BMSBMS200AMax. Continuous Output Power2560WMax. Continuous Charge Current200AMax. Continuous Discharge Current200AMax. Discharge Current 5 Seconds600ACHARGECharge MethodCC/CVCharge Voltage14.4V ± 0.2VRecommend Charge Current40A (0.2C)TEMPERATURECharge Temperature0℃ to 50℃ / 32℉ to 122℉Discharge Temperature-20℃ to 60℃ / -4℉ to 140℉Storage Temperature-10℃ to 50℃ / 14℉ to 122℉Low-Temperature ProtectionYes (32℉/0℃)Low-Temperature Charging Protection Auto RecoveryYes (41℉/5℃)OTHERSTerminalsM8 boltsWeight Approx.45.22lbsSizeL19*W6.7*H9.5 inchHousing MaterialABS (Flame Retardant Plastic)Protection ClassIP65 Packing list 12V 230Ah PLUS LCTP LiFePO4 Battery Pack *1 Service Card *1 Product Manual *1 Please be noted: battery charger is not included. On Apr 24, 2024 at 22:38:56 PDT, seller added the following information:
