T Branch Solar Panel Cable Photovoltaic Connector Male to Female Connectors CE
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Power Source | Solar |
| Color | Black |
| Material | PPO |
| MPN | SA3SA4SA51031345 |
| Brand | Artec |
| Type | Solar Panel |
| Water Source | IP65 |
| Voltage | 901-1000 V |
| Model | solar panel connectors |
| Connector Type | MC4 |
| Recommended Environment | Indoor/Outdoor |
| Country/Region Of Manufacture | China |
| Resistance Properties | Abrasion Resistant |
| Application | Home/Garden |
Specification:2 branch:T Type Male/Female Solar Panel Cable Connectors:one female to double male (F/M/M)and one male to double female (M/F/F)Insulation Material: PPOColor: BlackContact Material: Copper,Silver PlatedRated Current: 50ARetaed Voltage: 1000 VDCTest Voltage: 6000 VDC (50Hz,min)Protection Class: IIContact Resistance: 0.5 mΩTemperature Range: -40℃ to +90℃Protection Degree: IP67/IP2Flame Class: UL94-VOInsertion force: ≤ 50NWithdrawal force:≥ 50N 3 branch:T Type 3 branch Solar Panel Cable Photovoltaic Connectors MFFF FMMM IP65Color : BlackMaxi operating current : 30A;Temperature : -40 ~ 90;Safety class :CIass II;Waterproof rating : IP65;Maximum voltage : DC1000V. 4 branch:AC/DC Solar Branch Connectors MFFFF FMMMM IP65Color : BlackMaxi operating current : 50A;Temperature : -40 ~ 90;Safety class :CIass II;Waterproof rating : IP65;Maximum voltage : DC1000V. 5 branch:Terminal dimensions:Φ4.0mmAdapter cable:2.5mm2～6.0mm2 / 14AWG～10AWGRated voltage:TUV 1000V DC / UL 600V DCColor : BlackMaxi operating current : 20A~30A;Temperature : －40℃～+85℃Safety class :CIass II;Waterproof rating : IP67(IEC 60529);Maximum voltage : DC1000V.Test voltage:DC 8KV 1minInsulation Materials:PPOFlammability rating:UL94V - 0T-Branch Connector - 1 male to 5 femaleT-Branch Connector - 1 female to 5 maleContact resistance : ≤ 5mΩTerminal material ; copper,plate,tin 6 branch:Male to Female 6 branch MC4 Solar Panel ConnectorSix in one or one out of six.Rated current : 50ATerminal dimensions:Φ4.0mmAdapter cable:2.5mm2～6.0mm2 / 14AWG～10AWGRated voltage:TUV 1000V DC / UL 600V DCColor : BlackTemperature : －40℃～+85℃Safety class :CIass II;Waterproof rating : IP67(IEC 60529);Maximum voltage : DC1000V.Test voltage:DC 8KV 1minInsulation Materials:PPOFlammability rating:UL94V - 0T-Branch Connector - 1 male to 6 femaleT-Branch Connector - 1 female to 6 maleContact resistance : ≤ 5mΩTerminal material ; copper,plate,tin Package included:1 Pair Connectors Note:Please allow 1-3cm difference due to manual measurement.Due to light and screen difference, the item's color may be slightly different from the pictures.
